Product Summary

The DCP010505DBP-U is a 1W, unregulated, isolated DC/DC converter. It provides extra features such as output disable and synchronization of switching frequencies. It is suitable for point-of-use power conversion, ground loop elimination, data acquisition, industrial control and instrumentation and test equipment.

Parametrics

Absolute maximum ratings: (1)Storage temperature: -40 to +125℃; (2)Lead temperature (soldering, 10s): +270℃.

Features

Features: (1)Up To 85% Efficiency; (2)Thermal Protection; (3)Device-to-Device Synchronization; (4)Short-Circuit Protection; (5)EN55022 Class B EMC Performance; (6)UL1950 Recognized Component; (7)JEDEC DIP-14 and SOP-14 Packages.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
DCP010505DBP-U
DCP010505DBP-U
Texas Instruments
DC/DC Converters Mini 1W Iso Unreg DC/DC Converter
Data Sheet
0-1: $7.22
1-10: $6.49
10-25: $5.78
25-50: $5.45
DCP010505DBP-U/700
DCP010505DBP-U/700
Texas Instruments
DC/DC Converters Mini 1W Iso Unreg DC/DC Converter
Data Sheet
0-540: $3.75
540-700: $3.75
700-750: $3.68
750-1000: $3.61
DCP010505DBP-UE4
DCP010505DBP-UE4
Texas Instruments
DC/DC Converters Mini 1W Iso Unreg DC/DC Converter
Data Sheet
0-1: $7.22
1-10: $6.49
10-25: $5.78
25-50: $5.45
DCP010505DBP-U/7E4
DCP010505DBP-U/7E4
Texas Instruments
DC/DC Converters Mini 1W Iso Unreg DC/DC Converter
Data Sheet
0-540: $3.75
540-700: $3.75
700-750: $3.68
750-1000: $3.61
